SMA905 Fiber Optic Cable Connectors PC UPC APC Polish Metal Ferrule

Brand Name : CLX

Model Number : SMA 905

Place of Origin : Guangdong,China

MOQ : 200 Piece

Price : Negotiable

Payment Terms : T/T

Supply Ability : 10000 Piece/week

Delivery Time : 5-8 work days

Packaging Details : Bags packed by Carton ,OEM bag/Carton optional

Product name : Fiber Optic connector

Model : SMA 905

Certification : CE RoHS SGS

Application : Military, medical

Material : Metal and plastic

Ferrule End-face : PC, UPC,APC

Contact Now

SMA905 fiber optic connector with metal ferrule for Medical/Laser/Energy

Application

1. Military

2. Industrial

3. Laser Systems

4. Spectrometers

5. Medical / Surgical

Specifications

Mode	SM		MM
Polish	UPC	APC	PC
Insertion Loss	Typical ≤0.2dB Maximum ≤0.3dB		≤0.25dB
Return Loss	≥50dB	≥65dB	≥35dB
Interchangeability	≤0.2dB
Repeatability	≤0.1dB
Durability	≤0.2dB (1000 times mating)
Tensile Strengh	> 10kg
Temperature	≤0.2dB (-40+85 sustain 100 hours)
Humidity	≤0.2dB (+25+65 93 R.H.100 hours)

Description

The SMA-905 Connector, also know as FSMA Connector, was one of the first fiber optic interconnect system that gained industry wide acceptance. Today the connector is still widely used for military, industrial, and medical applications.

Feature

1. TIA / IEC compliant

2. Threaded nut connector

3. Simple termination and assembly

4. Stainless Steel or Zirconia ferrule with custom ID sizes up to 1500um

SMA905 Fiber Optic Cable Connectors PC UPC APC Polish Metal Ferrule
